Zanda Stainless Steel Fixed Pin Butt Hinge – 100 x 200 x 3.2mm (5926.SS)
Designed for maximum strength and door stability, the Zanda 5926.SS Fixed Pin Butt Hinge is the largest in its range, with a 200mm throw and 3.2mm thick stainless steel body. Ideal for heavy or wide doors in commercial environments, this hinge meets the highest standards for performance, longevity, and fire resistance. Whether you're fitting a high-use entry or a fire-rated passageway, this hinge is engineered to exceed expectations.
Key Features
- Extra-large 200mm width for superior lateral support
- Fixed pin design prevents disassembly and tampering
- 304 Grade Stainless Steel construction
- Fire rated for 4 hours (AS1905.1)
- Cycle tested to 200,000 operations on 120kg doors
- Supplied with fixing screws for timber installation
Specifications
- Part Code: 5926.SS
- Hinge Type: Fixed Pin Butt Hinge
- Material: 304 Grade Stainless Steel
- Finish: Satin Stainless Steel
- Size: 100mm (H) x 200mm (W) x 3.2mm (T)
- Fire Rating: AS1905.1 – 4 Hours
- Cycle Rating: 200,000 cycles on 120kg door mass
Available Finish Options
-
Stainless Steel
Suitable Uses
- Heavy commercial entry doors
- Extra-wide timber doors requiring greater throw
- Fire-rated installations (up to 4 hours)
- Industrial and institutional buildings
Item Code List
Care Tips
- Use a soft cloth to remove dirt and debris weekly
- Apply a stainless steel polish in coastal environments to prevent tea staining
- Avoid abrasive cleaners or solvents
Includes
- 1 x Zanda 5926.SS Fixed Pin Butt Hinge
- Timber fix stainless steel screws
 |
